Golden Vision Mono LCD Display 256*96 STN-Blue/Negative/Transflective LCD Module

Home

Monochrome LCD Display

Golden Vision Mono LCD Display 256*96 STN-Blue/Negative/Transflective LCD Module

STN-Blue LCD Display
Monochrome STN LCD Display

Golden Vision Mono LCD Display 256*96 STN-Blue/Negative/Transflective LCD Module

Part No: GVH25696101-FGFW

Display mode: STN-BLUE/Negative/Transflective

Driving condition: 1/128 duty, 1/12 bias, vdd=3.3V

Module Size: 187x76.3 MM

Display Area: 176.62x59.5 MM

Number of Dots: 256x96

View angle: 6:00 o'clock

Driver IC: ST75256

Interface Pins: 22 pins SPI

Operating Temp: -20~70

Storage Temp: -30~80

LCD connector: COG+FPC

Backlight: white LED*16, VF=3.0V, IF=240mA



Inquiry now

Product Features:

This is a STN-Blue/negative/transflective mono liquid crystal display (LCD) with a resolution of 256x96. It comprises an LCD panel, driver IC, FPC, and backlight, with customizable backlight brightness available upon request. Our experienced team is equipped to provide tailored solutions to meet your specific needs. This display is suitable for applications in electric meters, instruments, home appliances, printers, scanners, and medical equipment.



Product Drawing:
